Aluminum composite panel with NANO coating

Introduction

Aluminum Composite Panels (ACPs) have revolutionized the construction and design industries with their versatility, durability, and aesthetic appeal. But when combined with advanced nano coating technology, these panels reach a whole new level of performance. In this article, we explore the features, benefits, applications, and reasons why PremiumBond is the trusted supplier of ACP with nano coating.

Aluminum composite panel with nano coating while having properties such as Anti-pollution, fire resistance, good strength, etc., due to the benefit of superior nano-meter technology It also has unique properties such as self-cleaning, resistance to acidic and alkaline substances.

Nano composite aluminum, while having properties such as anti-pollution, good strength, etc., due to the superiority of nano-meter technology, has unique features such as self-cleaning, resistance to acidic and alkaline materials.

Therefore, according to the above features, when using nano-sheet compared to conventional PVC sheets, There are no more worries about cleaning facade surfaces, especially high-rise buildings.

Aluminum Composite Panel is a high-performance, lightweight material composed of two thin aluminum sheets (typically 0.5mm to 3mm thick) bonded to a non-woven plastic core (usually polyethylene or polyester). This sandwich structure gives ACPs exceptional strength-to-weight ratio, making them ideal for a wide range of applications.

Common Specifications:

• Thickness: 3mm, 4mm, 5mm
• Width: 1250mm, 3200mm
• Length: Up to 6000mm

Primary Applications:

• Exterior & interior wall cladding for buildings, hotels, and offices
• Ceiling designs in malls, airports, and residential spaces
• Furniture & cabinetry (e.g., kitchen countertops, shop fronts)
• Industrial & commercial facades

A nano coating is an ultra-thin (25–30 microns) protective layer applied to both sides of the ACP. This layer is made from advanced nanomaterials such as nano silicone, titanium dioxide (TiO₂), or mineral nanoparticles. The coating works on a microscopic level to enhance the panel’s properties.

How Nano Coating Works:

• Hydrophobic & Oleophobic Surface: Repels water, oil, dust, and stains.
• UV Protection: Blocks up to 99% of harmful UV rays, preventing color fading.
• Self-Cleaning: Rainwater forms beads on the surface, carrying away dirt (lottery effect).
• Anti-Scratch & Self-Healing: Minor scratches repair themselves within 24 hours.

Aluminum composite nano panel from a protective layer that has automatic cleaning properties, Easily removes dust on the surface of the paint and breaks down dirt Or in other words, it has an automatic cleaning property.

When it rains for a long time, black spots appear between the cracks, which are difficult to clean and have a bad effect on the appearance that the nano-panel has solved this problem. Soil and dust stick to it.

Composite Panel. This new generation of ACPs has this capability to combine P.V.D.F coating with NANO micro structure which due to self cleaning and non-wet ability functions along with an exceptional feature of dazzling Shining High Gloss.

NANO ACP itself has the self cleaning function so dirt can not attach onto it easily. Therefore cleaning job is very easy ,operator can use nature water to wash the panel face ,dust will disappear ,no any scratching marks ,A new bright cladding face will appear again.

It will give the building a consistently new look and can lower your maintenance costs a lot. The strong NANO P.V.D.F layer is coated on front aluminum coil. Because of its prominent feature, the panel becomes more and more commendable in market.

ordinary other P.V.D.F/NANO ACPs . So, with their bright sparkling and metallic effects, the special effect colors provide a particular eye-catching impression.

Making a striking design statement with your building. Give it shine and luster with a modern engineered facade of this Premiumbond _U.S.A innovative ACPs. The metallic sheen created with shining range plays with the light to create unexpected colors and effects.

✅ 1. Exceptional Durability & Weather Resistance

• Waterproof & Moisture-Resistant: Perfect for humid environments (coastal areas, bathrooms).
• Wind & Earthquake Resistance: Lightweight yet strong enough to withstand high winds and seismic activity.
• Corrosion-Resistant: The nano coating prevents aluminum oxidation, ensuring a long lifespan.

✅ 2. Long-Lasting Color & Beauty

• UV-Resistant: Colors stay vibrant for over 30 years without fading.
• Temperature Resistance: Stable in extreme temperatures (–40°C to +120°C).

✅ 3. Scratch & Abrasion Resistance

• Even with daily use, the surface remains smooth and flawless thanks to the self-healing nano layer.

✅ 4. Easy Maintenance & Self-Cleaning

• Cleaning: Wipe with a soft cloth, warm water, and mild detergent.
• Self-Cleaning: Rainwater naturally wipes away dust and pollutants.

✅ 5. Fire Safety & Low Smoke Emission

• Complies with ASTM E84 standards, classified as Class A (low smoke and flame spread).
• In case of fire, the nano coating reduces toxic gas emission and protects the panel from direct flames.

✅ 6. Eco-Friendly

• Made from recycled materials.
• Long lifespan (30+ years) reduces construction waste.

Through the perfect combination of modern nanotechnology and traditional aluminum-plastic panel production industry, Premium Bond has developed a new type of aluminum composite panels, which is nano aluminum composite panel.

Nano-aluminum composite panels are self-cleaning products designed for the requirements of modern architectural decoration. Compared with other metal curtain wall materials and interior wall decoration materials, it has the appearance quality, mechanical properties and weather resistance which are not inferior to the former, and has the superior characteristics of self-cleaning, environmental protection, energy saving, light weight and easy processing. Therefore, it is highly sought after by designers, engineers and owners.

🌟 1. Certified Quality

• All our ACPs are manufactured under ISO 9001 and ASTM standards.
• Each batch undergoes rigorous testing: UV exposure, fire resistance, salt spray, and impact tests.

🌟 2. Unmatched Color & Design Variety

We offer over 150 colors and patterns, including:

• Metallic finishes (Gold, Silver, Bronze)
• Pastel tones (Green, Blue, Pink)
• Wood grain designs (Oak, Walnut, Pine)
• Modern textures (Gradient, Geometric, Metallic)
• Custom Colors: Available in RAL or Pantone codes.

🌟 3. Long-Term Warranty

• 10-Year Warranty on nano coating & color fastness.
• 5-Year Warranty on panel construction.

🌟 4. Professional Support & After-Sales Service

• Free design consultation and project planning.
• Technical guidance for installation and maintenance.
• Free samples to test quality before bulk orders.

🌟 5. Fast Delivery & Competitive Pricing

• Production and delivery within 15 working days.
• Direct factory prices – no middlemen.

PREMIUM BOND get a patent for nano-PVDF panel which has the following advantages.
– Excellent easy-cleaning.
– Pollution Resistance
– Oil resistance
– Good Friction Resistance
– Strong Acid & Alkali Resistance
– Outstanding weather resistance

The aluminum composite panel is one of the materials that is widely used for a variety of structures, products, and buildings. In the construction, due to the cost efficiency and complexity of work, highly welcomes materials such as aluminum composite panel, which has many advantages and only few disadvantages.

At the same time, the construction profession faces numerous limitations and sensitivities. One of these sensitivities is the cleaning of towers and skyscrapers that have a composite aluminum panel appearance. Cleaning a building is important, even for low-rise buildings. However, the facade of a building and its cleanliness is involved in maintaining the appearance and value of the facade and the building as a whole. Also, in larger and more polluted cities, this importance is doubled.

But in the meantime, there are nano-aluminum composite panels that have solved this problem. In this way, in their production, nanotechnology has been used to clean the aluminum surfaces of the composite panel on its own, without the need for special chemicals and specialized methods.

Installation is simple, fast, and can be done using three main methods:

1. Aluminum Frame System
   • Ideal for exterior facades.
   • Panels are fixed to an aluminum subframe with screws or clips.
2. Click System
   • Perfect for interior applications.
   • Panels interlock without tools – just click them together.
3. Screw & Anchor Fixing
   • Used for large-scale projects.
   • Panels are secured with screws to a solid backing.

Tip: Always install panels in the direction of natural light to maximize their aesthetic appeal. Avoid using harsh chemicals during installation.
