ALUTILE composite sheet

ALUTILE Aluminium Composite Panel

ALUTILE composite sheet from the beginning of entry into Iran according to the needs of the construction industry and defined standards
In this regard, it has always sought to increase the quality of this product,
For this purpose, using modern technology and factory technology
Because PPG America, Henkel Germany and using the knowledge of European engineers and experts have been able to
With the approval of CE, it has been licensed to enter the competitive European market
And after that, for the first time in the country, he succeeded in receiving a “technical certificate from the Building and Housing Research Center” of Iran.

Technical specifications of ALUTILE composite sheet :

The 3003H16 alloy composite ALUTILE , manufactured by South West Aluminum, is manufactured according to the UK GB / T3190-96 standard, and this alloy has anti-corrosive properties due to its elements including Ti, Zn, Ni, Si, Mg and…. Corrosion) is very high.
The total thickness of the ALUTILE sheet is 4 mm and the thickness of each of the aluminum layers is 0.5 mm, which is a feature for use in the exterior of the building.
Bynel Resin CXA 30E753 sheet resin is used to integrate aluminum and polyethylene layers of E.I. factory products. Dupont DE Nemouors And Company is an American company that does not separate the layers from each other due to atmospheric factors.
The polyethylene used in L-LDPE composite sheet is of high stability against flame retardant.
It should be noted that this polyethylene is non-toxic and unlike most similar products, it is not recyclable and no impurities are found in it, which increases the useful life of the panel.
The surface paint of ALUTILE composite sheet is PVDF type, which is used in three layers with a total thickness of 35 microns by Coil Coating method (magnetic coating). This paint, which is a product of the American PPG factory and has a very high resistance to atmospheric factors such as ultraviolet rays of the sun, moisture, temperature changes, which ensures a very long stability of color quality.

Learn more: Types of composite sheet brands

The resin used in ALUTILE composite sheet (molecular film) to integrate the color of the surface and aluminum is the product of the German Henkel factory, which prevents cracking and separation of the paint from the aluminum surface.
The protective layer of the top of the sheet is Protective Film with a thickness of 0.8 mm.
And is a product of the French Novacel factory. The high quality of this layer prolongs the allowable time (6 months) to remove it from the sheet.
ALUTILE is one of the few composite sheets produced
On the back of the sheet, a protective paint is applied on the aluminum.

The cost of renovating the facade

مطالعه بیشتر

* It should be noted that according to studies conducted by
The U.S. Geological Survey and the National Research Center Of Testing Techniques For Building Materials China
, Aluminum Alloy Composite Panel Based on US ASTM Standards
And GB / T 17748-1999 UK produced and supplied.

It is noteworthy that ALUTILE Panel, as the first and only composite,
has the approval of the Iranian Building and Housing Research Center.
